assortment informations new products 07.-08.2020
331375 Torque wrench GEDORE
Gedore DREMOMETER 8586, lightweight, rugged and resistant with double-square drive, ideal for
use in workshops and almost all industrial manufacturing plants. Automatic rapid release with tactile and
audible signal, values are not shifted and accuracy is not impacted as a result of using both hands or the
actuation button being situated in a location other than the handle (as is the case with conventional torque
wrenches). Both the square drive and centre of rotation are on one axis, resulting in high operating safety;
can be extended to reduce the user‘s workload. Classified in accordance with DIN EN ISO 6789-2:2017
Type II Class A, including traceable test certificate, calibrated to a maximum permitted deviation of ±
3% and therefore more precise than the value of ± 4% required by the standard.
Order ID Type Range Division Drive Length
Nm Nm mm
331375.0100 8586-01 600...1500 25 1“ 1608
331380 Torque wrench GEDORE
Gedore DREMOMETER 8572 F, lightweight, rugged and resistant, ideal for use in workshops and almost
all industrial manufacturing plants. Automatic rapid release with tactile and audible signal, values are not
shifted and accuracy is not impacted as a result of using both hands or the actuation button being situated
in a location other than the handle (as is the case with conventional torque wrenches). Both the square
drive and centre of rotation are on one axis, resulting in high operating safety; can be extended to reduce
the user‘s workload. Classified in accordance with DIN EN ISO 6789-2:2017 Type II Class A, including
traceable test certificate, calibrated to a maximum permitted deviation of ± 3% and therefore more
precise than the value of ± 4% required by the standard.
Order ID Type Range Division Drive Length
Nm Nm mm
331380.0100 8572-01 1500...3000 50 1 1/2“ 2454
331585 Electronic torque/rotational angle wrench GEDORE
Gedore E-TORC II, electronic torque wrench for small series assembly as well as applications in quality
assurance, test laboratories and rework stations. High torque measurement accuracy ± 1%, ± 1 digit
of the read value, a visual, audible and sensory signal is issued when the set screw connection parameter
is reached; the screw tightening value is displayed via an LED progress bar. High-contrast graphic display
with backlight. The aluminium enclosure and ergonomically shaped handle enable safe and easy use even
at high tightening torques. Ergonomic operating button positioned on the side. Factory certificate in ac-
cordance with DIN ISO 6789 Type I Class C. RS232 serial interface for PC (USB adapter included in scope
of delivery).
Scope of delivery:
331585.0100...331585.0500: Analysis software, RS232 and USB data transmission cables, software
and
instructions — in rugged sheet metal case
Appropriate batteries:
2 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID Type Range Drive Plug connection Length
Nm mm mm
331585.0100 ET2SKA 25 2...25 1/4“ - 347
331585.0200 ET2SKA 150 10...150 1/2“ 9 x 12 514
331585.0300 ET2SKA 300 30...300 1/2“ 14 x 18 753
331585.0400 ET2SKA 600 100...600 Ø 22 - 1055
331585.0500 ET2SKA 1000 100...1000 Ø 28 - 1488
