assortment informations new products 06.2020
048477 Roughness tester MITUTOYO SURFTEST SJ-500
SURFTEST SJ-500 measuring instrument for simple and accurate measurement of surface roughness.
Datum plane system (inductive) for measuring primary profiles, roughness profiles, waviness profiles and
more. The built-in joystick enables quick and easy positioning. The manual adjustment knob allows you
finely position the stylus, for example when measuring the inside surface of small holes. The probe system
can be displaced to the side by 90°, making it ideal for measuring crankshafts or narrow spaces in trans-
verse scanning.
Features:
User-friendly 7.5‘‘ LCD touch panel (colour)
Graphical representation of the profile
Integrated thermal printer
Tilt compensation
Analysis of levels and straightness
Automatic compensation for radius/tilt/circle/ellipsis
Evaluation of tolerances (colour)
Statistics function (max./min./standard deviation, etc.)
Can be adjusted to any measurement length
Auto-calibration function
DIN EN ISO, VDA, JIS, ANSI
16 languages, password protection,
Several parameters:
Ra, Rq, Ry, Rz, Rq, Rt, R3z, Wte (45 in total)
Filter: 2CR75, PC75, Gauss, RobustSpline
Data output:
RS-232C, Digimatic, USB
Note:
We recommend training for this product!
For further technical information, please request a special brochure or consultation.
Scope of delivery:
Device with integrated thermal printer, feed unit with standard buttons, mains adapter/batteries, carry
case.
Order ID 048477.0100 048477.0200
Type SJ-500 SJ-500
Range µm 800/80/8 800/80/8
Resolution µm 0.01/0.001/0.0001 0.01/0.001/0.0001
Feeder length mm 50 50
Probe sections mm 0.025...25 0.025...25
Measuring force mN 0.75 4
Tip angle 60° 90°
Version Stylus Tip radius 2 μm Stylus Tip radius 5 μm
326659 Reversible ratchet HAZET

HAZET 863HP HiPer, DIN 3122, ISO 3315, small operating angle (4°) makes it ideal for use in the
narrowest of spaces, fine-toothed, 90 teeth, with safety lock. High power with VPA-tested static torque
up to 120 Nm in accordance with DIN 3122. Two-component handle with integrated suspension option,
chrome-plated, polished head.
Order ID Type Length
mm
326659.0100 863HP 116
329135 Hexagon insert bit STAHLWILLE

Stahlwille 54IC for hex socket screws, with pin guide, chrome alloy steel, chrome-plated.
Order ID Wrench size Pin length Length
mm mm mm
329135.0100 5 22 60
329135.0200 6 22 60
329135.0300 8 22 60
329135.0400 10 22 60
329135.0500 12 20 60
329135.0600 14 20 60
